Rolling Sheet Doors from the Overhead Door Company of Huntsville

Rolling Sheet Doors in Huntsville, Alabama and the surrounding Metro Areas

Rolling Sheet Doors by Overhead Door Company™

Simple security.

Rolling Sheet Doors

Serving all the areas in North Alabama

When your project requires attractive and solidly constructed rolling steel doors are also easy on your budget, Overhead Door Corporation’s rolling sheet doors are a perfect solution. These door systems incorporate innovative design elements that enable fast installation and ensure smooth operation for enhanced door life. Key features include quick-connect components that simplify installation without sacrificing strength.



About Rolling Sheet Doors

Here’s what makes our Rolling Sheet Doors different.

Available in a variety of colors and sizes to fit openings from 3′ wide by 7′ high to 20′ wide by 16′ high, these full-feature doors are an ideal choice when functionality is as important as value, quality and aesthetics.

Model 790CW

When your project requires a door that can handle high wind load conditions, yet is attractive, versatile, and economical, the 790CW fits the job. It is designed for fast installation, smooth operation, and low maintenance.

Special Design Features For Wind Load Applications.

The heavy-duty guide allows a rolling sheet door system to meet stringent wind load specifications.

Curtain wind locks reinforce curtain and enhance wind load performance and smooth operation.

26-gauge, roll-formed, galvanized steel.

Wind Load
22/-22 PSF (107/-107 kgf/sq m)

Max Width: 20’ (6096 mm)
Max Height: 20’ (6096 mm)
Insulation: Non-Insulated
Warranty: 15 Month Limited Warranty

Model 780 CD

The 780CD is designed for medium-duty usage environments where a high wind load-rated door is not required. It features quick and easy assembly without sacrificing stability or durability.

Material
High strength steel

Curtain
26-gauge, roll-formed, galvanized steel.

R-Value
Non-Insulated

Max Width: 16’ (4877 mm)
Max Height: 16’ (4877 mm)
Insulation: Non Insulated
Warranty: 15 Month Limited Warranty

Model 770 SS

The Model 770SS is ideal for lighter-duty self-storage facilities that require a quality door that installs quickly, operates dependably, and requires minimal maintenance.

Material
High strength steel

Curtain
26-gauge, roll-formed, galvanized steel.

R-Value
Non-Insulated

Max Width: 10’ (3048 mm)
Max Height: 10’ (3048 mm)
Insulation: Non InsulatedWarranty: 15 Month Limited Warranty

Want to learn more?

Features:

  • Strong And Durable Construction For Improved Operation And Door Life.
  • High-strength galvanized steel curtain enhances strength and maximizes wind load performance.
  • Unique curtain profile facilitates smooth operation and minimizes curtain damage.
  • Stepped rings allow tight, uniform curtain wrap and minimize headroom requirements.
  • Abrasion-resistant polypropylene webbing along both guide edges improve door operation, minimize curtain nesting and scratching.
  • Bearings prevent steel-to-steel contact, improve door operation and increase door shaft life.
  • Extruded aluminum-reinforced bottom bar assembly enhances door strength and operation.
  • Bulb-type astragal ensures a tight seal to the floor.
  • Lock assemblies enhance door system security.

Fast And Easy Installation:

  • Quick-connect head plate eliminates the need for multiple fasteners (available on 770SS only).
  • Quick-connect bottom bar stops minimize fasteners and allow easy insertion of the curtain into the guides.
  • The universal guide allows fastening in concrete, masonry, or wood jambs and fastening or welding to steel jambs.
  • Through-hole design reduces sideroom requirements.
  • Non-handed chain hoist (780CD and 790CW) with quick-connect features simplifies and speeds installation on site.
