Sectional Steel Doors

sectional steel doors in Huntsville, Alabama and surrounding areas

Sectional Steel Doors – From the Brand You Can Trust. Overhead Door Company™

We offer a comprehensive line of sectional steel doors and insulated steel products that encompass one of the industry’s most complete selection of panel profiles, gauges, track styles and hardware for commercial sectional door systems.

Sectional Steel Doors

Learn more about sectional steel doors in Huntsville, Alabama.

Overhead Door of Huntsville’s™ comprehensive line of sectional steel and insulated steel products encompasses one of the industry’s most complete selection of panel profiles, gauges, track styles, and hardware for commercial sectional door systems. Flexible PVC bottom weatherseal lessens conductivity of heat and cold, minimizes air and water penetration, and accommodates irregular floor conditions. Baked-on, polyester paint finish eliminates field painting and provides long-lasting protection against the elements. Superior panel strength and well-engineered track design meet wind load requirements and codes. Heavy-duty track and hardware are fabricated of high-quality galvanized steel and engineered for precise, trouble-free performance.

Door Options

  • Glazing choices include DSB glass, plexiglass, tempered glass, clear Lexan, wire glass and polycarbonate.
  • Full-section or individual-panel glazing satisfies requirements for external light and visitor identification

  • Higher-cycle springs in optional 25k, 50k, 75k, or 100k-cycles promote long-life in high-usage applications
  • Solid construction withstands wind loading of 20 psf, with a higher wind load option to meet additional requirements

  • Optional steel strutting reinforces structural integrity on wider doors
  • Electric and chain hoist operation, aluminum sash sections with a choice of DSB, acrylic, polycarbonate, tempered, or wire glazing, as well as movable center posts, 3″ (76 mm) track and jamb seals

Features

  • 16, 20, or 24-gauge steel door panels results in a solidly constructed door for years of dependable service
  • Standard steel doors available in sizes up to 32’2″ (9804 mm) in width; 24’1″ (7341 mm) in heightInsulated steel doors available in up to 30’2″ (9195 mm) in width; 24’1″ (7341 mm) in height

  • Heavy-duty track and hardware are fabricated of high-quality galvanized steel and engineered for precise, trouble-free performance
  • Flexible PVC bottom weather seal lessens conductivity of heat and cold, minimizes air and water penetration, and accommodates irregular floor conditions
  • Insulated steel doors provide thermal efficiency with an R-value of 7.35

  • Baked-on, polyester paint finish eliminates field painting and provides long-lasting protection against the elements
  • Superior panel strength and well-engineered track are designed to meet many wind load requirements and codes

Insulated Sectional Steel Doors

Model 418

The insulated sectional steel door is a high-quality, heavy-duty door that provides protection against hot and cold environments. Fabricated of 16-gauge, flush galvanized steel exterior, these 2″thick doors offer an R-value of 7.35.

Model 422

The insulated sectional steel door model 422 is ideal for heavy-duty applications requiring protection against the elements. These doors feature a 2″ panel thickness with 7.35 R-value and a 20-gauge ribbed steel exterior.

Model 426

The insulated door model 426 is ideal for heavy-duty applications requiring protection against the elements. These doors feature a 2″ panel thickness with 7.35 R-value and 24-gauge ribbed steel exterior.

Model 432

The insulated sectional steel door model 432 offers a 2″ panel thickness, a nominal 24-gauge ribbed galvanized steel exterior, and a poly-bonded back cover. The polystyrene insulation provides an R-value of 7.35.

Non-Insulated Sectional Steel Doors

Model 416

The non-insulated model 416 features flush panel designs that are strong, durable and versatile. Featuring 16-gauge galvanized steel these doors are designed for heavy-duty commercial and industrial applications, these doors also offer many optional features that allow you to make a bold design statement without compromising functionality.

Model 420

The non-insulated sectional steel door model 420 features a ribbed exterior and are robust, durable and versatile. Featuring 20-gauge galvanized steel these doors are designed for heavy-duty commercial and industrial applications.

Model 424

The non-insulated door model 424 features a ribbed exterior and are strong, durable and versatile. Featuring 24-gauge galvanized steel these doors are designed for heavy-duty commercial and industrial applications.

Model 430

The non-insulated sectional steel door model 430 is available in sizes up to 20’2″ in width and 16’1″ in height for a variety of medium-duty applications. These doors feature a 2″ panel thickness and a nominal 24-gauge ribbed, white galvanized steel exterior. The 430 Series is customizable to any project specification and offers a variety of available options.
